Overview Package Size 1201.00cm * 233.00cm * 215.00cm Package Gross Weight 37200.000kg UC-400 Heavy Duty Automatic Chang
Description
Basic Info.
| Model NO. | UC-400 |
| Certification | CE, ISO9001, ISO 14000 |
| Customized | Customized |
| Material | Metal/Stainless Steel/Iron |
| Application | Metal Cutting Machine, Metal Processing Machinery Parts, Metal Casting Machinery |
| Gross Weight | 7700kg |
| Electricity Demand | 30kVA |
| Transport Package | Wooden/Iron Bracket/Wooden Box |
| Specification | 4, 220*2, 680*, 3070mm |
| Trademark | Josen |
| Origin | Changzhou, Jiangsu, China |
| HS Code | 8457101000 |
| Production Capacity | 3000set/Year |
Packaging & Delivery
Package Size 1201.00cm * 233.00cm * 215.00cm Package Gross Weight 37200.000kgProduct Description
UC-400 Heavy Duty Automatic Changer Metalworking Vertical CNC Milling Machine with Metal Processing with 5 Axis
Product DescriptionBasic Info
| Number | Name | Number | Name |
| 1 | FANUC 0I-MF CNC controller | 10 | Chip pan and water tank |
| 2 | Full cover shroud | 11 | Transformer |
| 3 | Automatic lubricant system | 12 | Spindle air curtain dust protection system |
| 4 | Ground bolts and spacers | 13 | Mechanical, electrical and operating instructions |
| 5 | Tool-box | 14 | Rigid tapping |
| 6 | Working light | 15 | Electrical box heat exchanger |
| 7 | Warning light | 16 | Machine cleaning water gun |
| 8 | M30 automatic power-off system | 17 | Three-axis slide telescopic shield |
9 | Portable chip blowing air gun | 18 | 30-blade arm type tool magazine |
| Description / Machine Model | Unit | UC-400 |
| Travel | ||
| X-axis travel | mm | 700 |
| Y-axis travel | mm | 620 |
| Z-axis travel | mm | 600 |
| Distance from nose of spindle to table surface | mm | 20-620 |
| Working table | ||
| Working table size (X*Y) | mm | Φ400 |
| Table T-slot size (width * number of slots * spacing) | mm | 14H7/8*45°average |
| Max. loading capacity of working table | kg | 255(Horizontal)200(Slanted) |
| Spindle | ||
| Spindle motor (continuous/30 minutes) | kw | 11/15 |
| Spindle speed | rpm | 10-12,000 |
| Spindle Cooling method | Spindle oil cooler | |
| Spindle inner taper bore | BT40 | |
| Three axis | ||
| X/Y/Z axis motors | kw | 3/3/3 |
| Feed rate | ||
| Rapid feed rate (X/Y/Z) | mm/min | 36,000/36,000/36,000 |
| Fastest cutting feed rate | mm/min | 1-10,000 |
| Tool change system (optional) | ||
| Tool magazine capacity (standard/optional) | set | 24/30 |
| Tool magazine form | Arm type | |
| Latin form | MAS-P40-1(45°) | |
| Maximum tool diameter of adjacent tools | Ø80 | |
| Max. tool diameter of empty adjacent tool | Ø150 | |
| Maximum tool length | mm | 300 |
| Maximum tool weight | kg | 8 |
| Machine accuracy | ||
| Three-axis laser positioning accuracy (JIS6338 actual measurement method) | ||
| Positioning accuracy (full stroke) | mm | ±0.005 |
| Repeat positioning accuracy (full stroke) | mm | ±0.003 |
| System | ||
| Software | TCP4+1 | |
| Controller | FANUC 0I-MF | |
| Oil pressure system | ||
| Water tank capacity | liter | 250(front drainage)270 (rear drainage) |
| Pneumatic pressure requirements | kg/cm2 | 6 |
| Electricity | ||
| Power Specifications | AC380±10%,3 phase,60Hz/50Hz | |
| Electricity demand | KVA | 30 |
| Other | ||
| Chip removal method | Front crawler type | |
| Floor space (L*W) | mm | 4,220*2,680(front row)/2,780*3,150 (rear row) |
| Machine height (maximum) | mm | 3070 |
| Machine weight | T | 7.2 |
| Left elevation | Right elevation |
Machine Center Application: This VMC is suitable for mechanical processing and mold making .And it can adapt to the processing requirement from rough machining to finish machining .It can also finish many working procedures like milling ,drilling ,tapping ,boring ,etc.
Detailed Photos
A:We provide one year warranty, if any parts broken, we will send you a new one for free. 7.Before sending me an inquiry on our machine, it is better for you to provide me the following information?1)Your metal workpiece size. Because in our factory, we have different models according to working area.2)Your workpiece materials.Aluminum/Steel/Iron/Titanium Alloy?3) You also can send us the drawing of your workpiece, so that we can have a moe careful check and give your more accurate suggestions.
